QUICK DETAILS:
Model: UF500-2000
Brand: Fillpack
Power: 0.37kw
Voltage: 380V 3PH 50HZ or customized
Driven force type: Electrical
Automation degree: Automatic or Manual
Dimension: 1400*600*1600mm
Weight: 350kg
Application: Water purifying
Packing category: Wooden case
Packing material: Wood
Condition: New
PROPERTIES:
Capacity: 500-2000LPH
Key material: SUS304
Fuction: Filter for drinking water
Processing liquid: Sea water,Tap water ,Spring water,Brackish water
Origin: ZhangJiaGang, China
After sales service: Engineers avaliable to service overseas
Qualification: CE, ISO9001-2008
Packing: Wooden case packing.
Delivery Time: 30 working days after deposit
500-2000LPH Drink / Drinkable water treatment purification UF / ultra filter equipment / plant / machine / system / line
How Do Hollow fiber ultra filter Work & What Do They Do?
If you're looking for a water filterurification system that will provide outstanding drinking water for your home or factory, Ultra Filter (UF) purification system is one of the most popular and best water filtration methods available.
Hollow fiber ultrafiltration is a membrane separation technology widely used in the separation, concentration and purification of macromolecular substances. During ultrafiltration. Under the pressure, the aqueous solution flows through the membrane surface, and the solvent (water) and small molecular solute smaller than the membrane hole are permeable to the membrane to become the purified solution (filter solution). The solute and solute group larger than the membrane hole are intercepted and discharged with the water flow to become the concentrated solution. The ultrafiltration process is dynamic filtration, and the separation is completed in the flow state. The solute only deposited on the membrane surface, and the ultrafiltration rate decreased to a certain extent and tended to balance.
Features for pure Drinking / Drinkable water UF/ Ultra filter equipment / plant / machine / system / line
1. High-precision filter, the aperture of nano-level, the best water quality
2. Manual / electric control system automatically switch;
3. With a self-test, water-free point automatically open the system of water, water full stop, no pressure protection and other safety devices;
4. With automatic washing and water tank full automatic double wash function, can extend the life of UF membrane;
5. With on-line monitoring of water quality (conductivity display), flow and pressure on-line display;
6. Equipment integration, installation is simple, simple operation, no special duty;
7. Equipment failure with automatic alarm function;
8.High water production, high desalination rate, long service life;
9. Core components (pumps, RO membrane, electronic control systems, etc.) imported / domestic joint venture brand;
10. Equipment rack with stainless steel, low-pressure pipe for the UPVC material, high-pressure pipe using SUS304 stainless steel.
UF Water Purification System
Ultrafiltration water purification system is produced in cosmetics, food, electronics, chemical and other industries. It is favored by users because of its stable water quality and simple operation. The system solves the problem of frequent regeneration and cleaning during the use of the purification device. Ultrafiltration is one of the membrane separation technologies driven by pressure. The purpose is to separate macromolecules from small molecules.
The complete UF water treatment system including:
FRP filters : sand filter, active carbon filter
Cartridge filter
raw water pump
cleaning pump
4040 UF membrane
manual valve
UPVC connection pipes
Applications of Ultra Filter System:
1. Food and Beverages
2. Tube and Micro Circuit manufacturing
3.Pharmaceuticals
4. Hotels & Resorts
5.Hospitals, Mineral Water Processors
6.Power Generation
7. Electronic Component manufacturing
8. Semi conductors
1. the Water treatment machine is packed by wooden case.
2. The delivery date of Water treatment machine is within 30 days after payment.
Guarantee:
We response for one year warranty for the machine, however, it without any human conduct. And provide one-year free spare part for client. And send engineer to client’s company with client’s provision for flight charge and accommodation. Help install the machine, teaching their staff operate the machine and also, we do have a private school which help our client sending their staff to china, help them training.
After sales service:
1.Installation & adjustment
After the equipment are arrived at the customer’s site, the customer is responsible for unpacking and arranging the equipment according to the placement drawing; and does under our install-adjust technicians’ guidance. Costs of the staff are decided at last.
2.Training
We are responsible for offering the technical training to user. The training content includes the structure and maintenance of the equipment, control and operation of the equipment. Through training, users' technical staff can grasp and the skill of operation and maintenance proficiently, and deal with the general troubles in time. We will appoint qualified technical staff for the guidance.
The buyer can send staff to our company for learning.
3.Quality assurance
We guarantee the goods offered are brand-new, not used, with latest design and suitable material made, and we guarantee the specification of the equipment is consonance with the contract.
We guarantee the line achieve product technical performance indicators within 5 days after feeding operation through the correct guidance of the installation and commissioning.
We are responsible for the fault and damage of the production line caused by our design, technology, manufacture, installation, adjustment and material defect etc. that all belong to our responsibility.
The warranty period is 12 months after acceptance check of the production line. If there is any different between the furnished equipment in the customer’s factory and the equipment concerned in the contract, the users have the right to pass the inspection book to the legal department to claim for compensation to our company within goods warranty period.
4.Warranty
Offer 12 months maintenance period to the problem that caused by our design, manufacture and the material quality, and offer the relevant parts and effective service for free for above reason. We will offer a widely and favorable technical support, after service all the time after guarantee period.
