Piston Filling Machine

    Title: Roller adjusting paste filling machine for pulpy juice

    Key words: paste filling machine, sauce filling machine , sauce filler

Inquire Now
  • Quick Details
  • Detailed Descriptions
  • Packaging & Delivery
  • Services


    Model: HSCGF24-24-8

    Brand: FILL-PACK

    Power: 7.5kw

    Voltage: 380V 3PH 50HZ or customized

    Driven force type: Electrical

    Automation degree: Automatic

    Dimension: 2800*2300*2300mm

    Weight: 5500 KG

    Application: paste filling

    Packing category: bottle / can / jar

    Packing material: glass / metal / PET

    Condition: New


    Capacity: 10000 BPH (200ml)

    Applicable bottle size: 0-500 ml

    Key material: SUS316L

    Fuction: paste filling

    Rinsing head qty: 24 pcs

    Filling head qty: 24 pcs

    Sealing head qty: 8 pcs

    Origin: ZhangJiaGang, China

    After sales service: Engineers avaliable to service overseas

    Qualification: CE, ISO9001-2008

    The paste filling machine is integrated with washing, filling and capping functions. It is suitable for filling thick liquids like jam sauce. The most advanced technology from Japan and Germany is employed in the design. The piston same volume sucking filling is used. The filling is fast, the amount of material is accurately controlled and the dropping and leakage are avoided.

    Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180~ along the conveying rail. The efficiency of bottle washing is high.

    The magnetic torque is used for twist off capping. The power of capping can be adjusted without steps. The capping strength can also be fixed, and the caps will not be damaged, the capping is reliable.

    The whole machine is controlled by PLC with touch-screen as the human-machine interface. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.

    The frequency changing technology is used to adjust the operation speed steplessly. The production capacity can be displayed digitally and can be adjusted conveniently.



    Capacity (B/H)

    10000(within 200ml)

    Bottle size

    Neck :φ20-100mm:Height:100-320mm

    Water Pressure


    Water consumption(kg/h)


    Filling precision

    <+/- 5g (basing on 200g dosing)

    Air pressure


    Air consumption








    Sea worthy packing for yogurt filling machine

    50 working days for yogurt filling machine
