Oil Filling Machine

    Title: 1-5 kg oil filling machine with PLC dosing volume change system

    Key words: oil filling machine, piston filling machine , oil filler

Inquire Now
  • Quick Details
  • Detailed Descriptions
  • Packaging & Delivery
  • Services


    Model: HSG-8

    Brand: FILL-PACK

    Power: 0.3kw

    Voltage: 380V 3PH 50HZ or customized

    Driven force type: Pneumatic

    Automation degree: Automatic

    Dimension: 2000*1500*2200mm

    Weight: 800 KG

    Application: oil filling

    Packing category: bottle / can / jar

    Packing material: glass / metal / PET

    Condition: New


    Capacity: 0-500 BPH (5kg)

    Applicable bottle size: 0-5000 g

    Key material: SUS304

    Fuction: oil filling

    Filling head qty: 8 pcs

    Origin: ZhangJiaGang, China

    After sales service: Engineers avaliable to service overseas

    Qualification: CE, ISO9001-2008

    1-5 kg oil filling machine with PLC dosing volume change system

    A, Advanced design of oil filling machine

    1, East for changing bottles within minutes;

    2, Pneumatic plunger is the heart of the machine, is with special design, it can do correct filling and it is easy for cleaning;

    3, Strong point of the machine is the machine can fill sticky liquid and also semi-liquid.

    4, Control plunger process by hand wheel, every head filling qty can be made averagely;

    5, Capacity is selective on touch screen;

    6, Filling times can change from once to 4th basing no part change;

    B, Special filling method of oil filling machine:

    1, The filling volume is controlled by volume, is quite precision, when the container is arriving at the set position, the plunger will generate precision pressure;

    2, When there is foam generate during filling, the filling method can be adjusted, the filling head can go into bottle bottom to fill;

    3, The machine is set with automatic absorbing system, the extra liquid will be absorbed into filling head, no liquid will be outside of bottle and in filing machine;

    C, Precise control:

    1, Precision:: ±1%

    2, No bottle , no filling


    Filling range: 0-5000 g

    Capacity: 500 BPH (5000g )

    Air compression: 0.55-0.65Mpa 0.1M3/min

    Dimension: 2000*1500*2200mm

    Weight: 800kg

    Rotary oil filling machine photo for ref

    Sea worthy packing for piston filling machine

    20 working days for piston filling machine
