Title: PLC control OPP labeling machine to save label cost
Key words: OPP labeling machine, hot glue labeling machine, labeling machine
Model: OPP-300
Brand: FILL-PACK
Motor Power: 9.84kw
Voltage: 380V 3PH 50HZ or customized
Driven force type: Electrical
Automation degree: Automatic
Application: Labeling
Application label: OPP LABEL
Condition: New
PROPERTIES:
Capacity: 0-18000BPH
Key material: SUS304
Fuction: HOT glue opp labeling
Labeling head qty: 1
Labeling machine construction: LINEAR
Suitable bottle shape: round
Precision: +/- 1mm
Origin: ZhangJiaGang, China
After sales service: Engineers avaliable to service overseas
Qualification: CE, ISO9001-2008
PLC control OPP labeling machine to save label cost
Components of OPP labeling machine:
No | Spare Parts List | Brand | Origin | Remark |
1 | Label Feeding Servo Motor | Schneider | France |
|
2 | Label Feeding Servo Driver | Schneider | France |
|
3 | Encoder | Schneider | France |
|
3 | Inverter | Schneider | France |
|
4 | Air Swift | Schneider | France |
|
５ | Breaker Swift | Schneider | France |
|
６ | Relay | Schneider | France |
|
７ | Swift | Schneider | France |
|
８ | Switching Power Supply | Schneider | France |
|
9 | Lugs and terminals | / | Taiwan |
|
10 | PLC | Schneider | France | / |
11 | Touch screen | Schneider | France |
|
12 | Alarm | / | Taiwan |
|
13 | Vacuum pressure sensor | Schneider | France |
|
14 | Thermostat | Schneider | France |
|
15 | Solid Relay | Schneider | France |
|
16 | Label Roll Checking Sensor | SICK | German |
|
17 | Color Sensor | SICK | German | With intelligent |
18 | Glue Paste Snesor | SICK | German |
|
19 | Label Missing Checking Sensor | SICK | German |
|
20 | Bottle Fall Down Sensor | SICK | German |
|
21 | Bottle Feeding Sensor | SICK | German |
|
22 | Drive Motor |
| Taiwan |
|
23 | Conveyor Drive Motor |
| Taiwan |
|
24 | Glue Motor |
| Taiwan |
|
25 | Vacuum Pump |
| Taiwan |
|
26 | SS frame | 304 SS | China |
|
27 | Chain plate | FLEXON | Italy |
|
28 | Chain plate gear | FLEXON | Italy |
|
29 | Bear | NSK | Taiwan |
Parameters:
Labeling precision: +/-1mm
Speed: 300BPM
Power source: 50/60HZ, 3PHASES, 380V AC, 24V DC
Total power: 9.84kw
Main motor: 1.5kw
Servo motor: 1.5kw
Vacuum pump: 4kw
Glue melting machine: 2.0kw
Glue pump: 90w
Label sending motor: 0.75kw
Size: 3200*1524*2000mm
Weight: 1500kg
Air source: 4-6kg/cm2
Air consumption: 0.1N㎥/min
Air inlet: 3/8 inch
Operating condition: temperature:20℃~30℃(keep in dry place at the room's temperature)
1, It is a must to pack the OPP labeling machine well with wooden case since there is no frame to protect the precise elctronics.
2, 20-25 working days to produce the OPP labeling machine as clients’ samples provision for a quick delivery.
