Automatic Blowing Machine-1

CP-2000 type bottle blow molding line is suitable for blowing PET bottles of various shapes, volume from 100 ml to 2000 ml, wide application for blowing mineral water bottles, soda bottles, cola bottles..etc

1, Adopts advanced microcomputer control system, stable performance, the conveyor automatically send embryo;

2, Use infrared heating lamps, penetrating power strong, embryo heated while rotation, orbital revolution, heating uniformity, rapid and reliable;

3, Light tube in heating area, reflector width and height can be adjusted to suit the different structure preform heating, and automatic exhaust temperature device in order to ensure constant temperature of the drying tunnel;

4, Each machine has a safety self-locking device, when a processes have problem, the program will automatically switch to a safe state;

5, All the action drive by the cylinder, do not use pumps, with no pollution, low noise;

6, Gas way design divide action and air blowing into three parts, action to meet the needs of the different pressure of the blowing, action;

7, Cooling system to achieve the desired cooling effect; H- the bottle scrap rate less than 0.2%.

8, Pneumatic mould clamping made more stable operation; Blowing from bottom to top give higher correctness;

Parameters of bottle blow molding line
