HP Air compressor for 1+2 PET bottle blow molding machine

    Title:HP Air compressor for 1+2 PET bottle blow molding machine

    Keywords:air compressor,high pressure air compressor,HP air compressor

Inquire Now
  • Quick Details
  • Detailed Descriptions
  • Packaging & Delivery
  • Services

    QUICK DETAILS:

    Model: HP1230

    Brand: Shangair

    Power: 15kw

    Voltage: 380V 3PH 50HZ or customized

    Driven force type: Electrical

    Automation degree: Automatic

    Dimension: 1880×850×1050mm

    Weight: 580kg

    Application:  Pneumatic power for bottle blowing

    Packing category: Bottles

    Packing material: Plastic

    Condition: New

    PROPERTIES:

    Capacity: 1.2m3/min 30kg pressure

    Applicable bottle size: 0-2L

    Key material: SUS304

    Fuction: pneumatic power for bottle blowing

    Processing liquid: N/A

    Origin: ZhangJiaGang, China

    After sales service: Engineers avaliable to service overseas

    Qualification: CE, ISO9001-2008


    The air system has been divided into two parts:

    Pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.g devices safely. Main driver adopts stepless motor, conveyor speed is changed freely.


    Parameter for 1.2m3/min air compresspor:

    Air compressor

    1.2M3/30KG

    Volume

    1.2m3

    Pressure

    30Kg

    Speed

    800r/m

    Power

    15KW

    Overall Dimension

    1880×850×1050mm

    Weigh

    580Kg



    Parameter for 2.4m3/min air compresspor:

    Air compressor

    2.4M3/30KG

    Volume

    2.4m3

    Pressure

    30Kg

    Speed

    800r/m

    Power

    22KW

    Overall Dimension

    1910*1630*1180mm

    Weigh

    1000Kg


    Packing: Wooden case packing.

    Delivery Time: 15 working days after deposit.

    Guarantee:

    We response for one year warranty for the machine,  however, it without any human conduct. And provide one-year free spare part for client.  And send engineer to client’s company with client’s provision for flight charge and accommodation. Help install the machine, teaching their staff operate the machine and also, we do have a private school which help our client sending their staff to china, help them training.


    After sales service:

    1.Installation & adjustment

    After the equipment are arrived at the customer’s site, the customer is responsible for unpacking and arranging the equipment according to the placement drawing; and does under our install-adjust technicians’ guidance. Costs of the staff are decided at last.


    2.Training

    We are responsible for offering the technical training to user. The training content includes the structure and maintenance of the equipment, control and operation of the equipment. Through training, users' technical staff can grasp and the skill of operation and maintenance proficiently, and deal with the general troubles in time. We will appoint qualified technical staff for the guidance.

    The buyer can send staff to our company for learning.


    3.Quality assurance

    We guarantee the goods offered are brand-new, not used, with latest design and suitable material made, and we guarantee the specification of the equipment is consonance with the contract.

    We guarantee the line achieve product technical performance indicators within 5 days after feeding operation through the correct guidance of the installation and commissioning.

    We are responsible for the fault and damage of the production line caused by our design, technology, manufacture, installation, adjustment and material defect etc. that all belong to our responsibility.

    The warranty period is 12 months after acceptance check of the production line. If there is any different between the furnished equipment in the customer’s factory and the equipment concerned in the contract, the users have the right to pass the inspection book to the legal department to claim for compensation to our company within goods warranty period.


    4.Warranty

    Offer 12 months maintenance period to the problem that caused by our design, manufacture and the material quality, and offer the relevant parts and effective service for free for above reason. We will offer a widely and favorable technical support, after service all the time after guarantee period.
